ZeedaWallbox G Series

7.4kW 32A Single Phase EV Charger

ZeedaWallbox G Series

BAND

ZEEDA ENERGY

MODEL

G Series

POWER

DIMENSIONS

7kw

310*214*90mm

SPECIFICATIONS

  • Power: 7kW

  • Current: 32A

  • Voltage: One phase, 220V ÷ 15% AC

  • Frequency: 47-63Hz

  • Level of Measurement Accuracy: 1.0

  • Operating Temperature: -20°C ~ +55°C

  • Storage Temperature: -40°C ~ +85°C

  • Charging method: RFID/PLUG&CHARGE

  • Relative Humidity: 5-95%, without condensation

  • IP Rating: IP55

  • Residual Current Protection Rated Operating Current: 30mA

  • Residual Current Protection Rated Action Time: <0.1 s

  • Connector Power Line Contact: AC277V, 40A

  • Connector Operating Life: ≥ 10000 times

  • Altitude: < 2000m

PROTECTIONS

  • Undervoltage/Overvoltage Protection;

  • 0vercurrent Drorection:

  • Overheat Protection; |

  • Short Circuit Protection;

  • Leakage Protection;

  • Lightning Protection; |

  • Emergency Stop Protection.

CERTIFICATION

ZeedaWallbox G Series
